HYT-series 6 colour high speed Flexographic Printing Machine

0086-577-58910222
DESCRIPTION
 1. Low speed and full load startup; stable running by tension control when increasing and decreasing speed , noise is decreased
 2. High dots presentation rate under high speed; clear and vivid stratification of screen printing; strong stereo effect and accurate registering.
 3. Aluminum roller adopts the Japan semi-sealing small bearing; flinty oxidation, static and dynamic balancing treatments are conducted; low resistance and small flop.
 4. The special made modulus angular gears adopted; accurate printing size and full printing specifications (5mm is a spec)
 5. With the air exhaust, blowing and heating settings; the heating system adopts the central thermostatic control system and group management, also with the cold air forming devices.
 6. Printing rolls should keep moving while machine halted
 7. Material holder use air shaft
 8. Autotension control
 9. Unwind with auto deviation correction system (EPC)
10. EDGE position control
11. Reversible printing 6 color press for6+0, 1+5, 2+4, 3+3.
12. 1 sets of printing cylinder, sizes:   15 inches.

Printing  width
600mm - 1600mm
Printing material
PVC:35~70μm,OPP:20~70μm,BOPP:18~60μm,PE:35~100μm,
NY:20~50μm,PET:12~60μm,CPP:20~60μm,p   Paper:20~150g/m2
Printing color
at your own choice+ 2 special color
Printing length
7.5"~40"(190mm~1000mm)/7.5"~50"(190mm~1270mm)
Printing plate lifting system
Pneumatic press control
Machanical speed
100m/min
Printing speed
10~80m/min
Register precision
Longitude:±0.15mm    Transverse:±0.15mm
Rewinder/Unwinder DIA
Φ1200mm


<td width="124
Inquiry

If you have any enquiry about quotation or cooperation,please feel free to email us at ray@sanbi.comor use the following enquiry form. Our sales representative will contact you soon. Thank you for your interest in our products.

0086-577-58910222 0086-13566149933 ray@sanbi.com

1455 Songpu East Road, Nanbin Street, Ruian City, Zhejiang Province

All Rights Reserved © 2021 Zhejiang Bangtai Machinery Co., Ltd. 浙ICP備2021007445號(hào)-2 Powered by:Otree | Sitemaps | XML Privacy Policy
99久久精品国产毛片_处一女一级a一片AV_亚洲黄色网站在线观看_免费看一级一级人妻片_拍国产真实乱人偷精品
Printing  width
600mm
800mm
1000mm
1200mm
1400mm
1600mm
Material feeding width
700mm
900mm
1100mm
1300mm
1500mm
1700mm
Master motor
3.7Kw
3.7Kw
3.7Kw
5.5Kw
5.5Kw
5.5Kw
Rewinder motor
1.5Kw
1.5Kw
1.5Kw
2.2Kw
